Technical Fact Sheet
General Characteristics
- Declared Power: 377 MW
- Annual generation: 144,726 MWh
- Frequency: 50 Hz
- Average load factor: 4%
- Turbine flow 535.0 m3/s
- Net height of fall 76 m
Unit Characteristics
| Unit 1 | Unit 2 | Unit 3 | Unit 4 | Unit 5 | |
| Power per unit (MW) | 75 | 77 | |||
| Type of turbine | Francis | ||||
| Year placed into operation | 1968 | 1972 | |||
| Generator voltage (kV) | 13.8 | ||||
| Generator manufacturrer | Hitachi | ||||
| Type of transformer | Single-phase | Three-phase | |||
| Transformer power (MVA) | 85.5 | 85 | |||
| Relación de transformación | 13.8 / 69 / 230 | ||||
